Last reviewed and updated: 29 September 2026
Quick Answers
Components: A drive that moves the car, the car itself, the rails or enclosure it travels on, and the controls. Most UK home lifts need no shaft.
Using it: You call the lift, step or roll in, and hold the button until it reaches the other floor.
Drives and safety: Four drives are used: rope or drum, hydraulic, screw and nut, and vacuum. Most have a battery or safe-lowering system for power cuts.
This page explains what moves a home lift, what it runs on and what keeps it safe.
The Basic Components of a Home Lift
- Drive System: On most through-floor lifts the motor sits in the roof of the car and winds a rope or drum. Terry and Wessex use a hydraulic power unit, Aritco, Cibes and SWIFT a motor turning a nut on a long screw, and PVE a pump that changes the air pressure above the cabin.
- Lift Car: The car is where you stand, sit or stay in your wheelchair. Some are fully enclosed cabins, and some are open platforms with low sides.
- Lift Shaft: Through-floor lifts climb their own rails through a hole cut in the ceiling. Shaft lifts arrive with their own glass or panel enclosure, and vacuum lifts run inside a clear tube.
- Control System: Buttons in the car and at each floor, and often a remote. Most home lifts move only while the button is held.
How Home Lifts Operate
- Calling the Lift: Press the call button on your floor and the lift comes to you.
- Selecting a Floor: Inside, press and hold the button for the other floor.
- Movement: A through-floor lift at 0.15 m/s climbs 3 m in about 20 seconds; a hydraulic one at 0.06 m/s takes about 50.
What Keeps It Safe
- Battery lowering: In a power cut, a battery lowers the car to the floor below.
- Safety pan: A pan or sensors under the car stop it if it meets anything below.
- Interlocks: The lift will not move unless the doors or gates are closed.
- Cut-outs: Overload and overspeed cut-outs stop it if something is wrong.
How the Current UK Market Splits
For our Market Report 2026 we looked at how all 22 current UK models actually move. 64 per cent are self-supporting through-floor designs that carry their own weight on rails or a frame, which is why so many need no builder’s shaft. On noise, only one brand publishes a manufacturer-verified figure, the Cibes Cloud Plus at around 40 dB, about the hum of a fridge; the rest say “whisper-quiet” without a number, something we unpack in our home lift noise guide.
Summary
A home lift is a motor-driven car on rails or in an enclosure, with safety systems for power cuts and obstructions. The drive decides the speed, load, floors and power supply; our type comparison sets the four drives side by side.
